This large
1995 Cincinnati Sabre Vertical Machining Center has 26"y axis travel
by 26" z axis travel by 50" x axis travel. The Sabre has
large linear guide ways with linear encoders on all axis giving feedback to
a Fagor 8055 MC Conversational Control. This Sabre is equipped with a
horizontal and vertical 4th axis, thru the tool coolant, 10,000 rpm
spindle, 21 tool change carousel, spindle chiller. Machine is on a
DNC Network.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
This picture is of the headstock end
of our American 3220 CNC Lathe and the Fagor 8025 Control. This
lathe was remanufactured in 2000 with new and rebuilt ball screws, AC
Digital Drives, rebuilt x--axis, linear
encoder on x--axis, Eurotherm Main Spindle Drive.
The 3220W swings over 32" and 10' between centers.
Machine is on a DNC Network
Also pictured in front of the control is our Albion Temperature
Compensating Snap gage.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
The machine to the left is a Cincinnati
#6 Plain Horizontal and Vertical Milling Machine with overarm and
supports. This machine can take care of your heavy milling
requirements as the horizontal spindle is rated at 50 horsepower and the
vertical spindle is 5 horsepower. This machine has over 62"
of x axis travel, 12" of y axis travel, and 21" of z axis
travel. The table is 20" wide by 104" long.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
